Technical Specification
Laser wavelength | 10640nm |
Laser power | 0~100w serially adjustable |
Marking scope | 200X200mm~600x600mm (adjustable ) |
Marking speed | ≤7000mm/s |
Minimum character | 0.4mm |
Repeated precision | +0.003mm |
Cooling style | water cooling |
Average power consumption | ≤3kw |
Power supply | 220V/50HZ 25A |
G. W. | 180KGS |
Dimension | Optic system :1850×500×1610mm Control system :560×640×830mm Cooling system :490×610×790mm |
Packing Size | 1950X1450X1590mm |
MEAS: | 4.5CBM |
N.W.: 230KGS | G.W.:250KGS |
|
|
![]() |
